More bass without clarity is just noise. Bavsound's Ghost Underseat Subwoofers are engineered to be a plug and play replacement for your existing subwoofers, providing you with louder, cleaner and clearer bass.
Bavsound Ghost Underseat Subwoofers are designed to install directly into your BMW’s factory underseat subwoofer locations using the original mounting points and plug-and-play connectors. No additional parts or coding is required.
The current generation of Bavsound Ghost subwoofers supplied are the latest V3 revision, featuring refinements to the driver design and improved overall efficiency. This latest version continues Bavsound’s mission of delivering stronger, cleaner bass output while maintaining full compatibility with BMW factory audio systems.
Not sure which BMW audio system your vehicle has? Send us your VIN and we’ll confirm compatibility before you order.
HOW TO DETERMINE WHICH AUDIO SYSTEM YOUR VEHICLE IS EQUIPPED WITH
BASE STEREO SOUND SYSTEM¹
The base level stereo system is standard on most Australian delivered BMW models. Specifics vary by vehicle, but this audio system is generally characterised by the absence of an external amplifier and typically includes 6–8 total speakers, often without tweeters. Overall sound quality is generally quite limited compared to BMW's upgraded audio systems.
There is no specific option code for the Base Stereo system.
HI-FI SOUND SYSTEM - S676A
The Hi-Fi Speaker System comes standard on only a few Australian delivered models. Although the exact configuration varies from vehicle to vehicle, this system is generally characterised by approximately 10 speakers and an external amplifier, but without user-adjustable DSP processing or advanced equaliser settings.
The option code for this system in a VIN search is S676A.
HARMAN KARDON SOUND SYSTEM - S674A/S688A
If your BMW has Harman Kardon badges on the interior speaker grilles, then your vehicle is equipped with the Harman Kardon audio system.
If you do not see these badges, then your vehicle is not equipped with this system.
The option code for this system in a VIN search is typically S688A. On some earlier models such as the 1 Series and 2 Series, option code S674A may be installed instead. Both codes refer to BMW's Harman Kardon premium audio system.
TOP HI-FI / LOGIC7 / PROFESSIONAL DSP - S677A¹
This is BMW's premium audio system, referred to internally as Top Hi-Fi or Hi-Fi System Professional DSP.
Depending on the model and year of your BMW, this system may also be marketed under names such as Logic7, Premium DSP, or Professional DSP.
If your vehicle is equipped with one of these systems, or your VIN search shows option code S677A, then your BMW has this audio system.
If you own an M model BMW (M3, M5, etc.), your vehicle may instead be equipped with DIRAC or Enhanced Premium Sound (EPS). Please review the sections below or check with your dealer to confirm.
DIRAC SOUND SYSTEM - S752A²
Available only on certain BMW M models such as the M3, M5, and M6, the DIRAC system was BMW's highest-tier audio system at the time and positioned above the standard premium audio offerings.
Compared to the Top Hi-Fi (S677A) system, DIRAC systems feature upgraded speakers, a more powerful amplifier, additional DSP processing, and improved crossover design.
DIRAC systems can often be identified by silver trim rings around the door speakers and a metallic silver speaker cone visible through the front speaker grilles.
ENHANCED PREMIUM SOUND - S752A²
Also available only on certain BMW M models, Enhanced Premium Sound replaced the earlier DIRAC system as BMW’s highest-end audio option.
Compared to the standard premium systems (Logic7 or Harman Kardon), Enhanced Premium Sound features upgraded speakers, a more powerful amplifier, additional DSP processing, and improved crossover hardware.
Enhanced Premium Sound can be difficult to identify visually as it typically uses the same speaker locations as other premium BMW systems.
If you aren't sure what audio system your BMW is equipped with, simply send us your VIN number and we will be happy to assist you.
Your VIN will also be required when placing an order so we can ensure you receive the correct kit for your BMW.
¹ Some models such as the E60/E61 5 Series with S677A Top Hi-Fi use a 4 Ohm underseat subwoofer instead of an 8 Ohm version. Please contact us if you need help confirming which subwoofer set is suitable for your vehicle before ordering.
² Bavsound Underseat Subwoofers are NOT compatible with S752A audio systems.
DOUBLE THE BASS IN YOUR BMW IN ABOUT AN HOUR — WITHOUT MODIFYING YOUR FACTORY SYSTEM
The Bavsound Ghost BMW Underseat Subwoofer Upgrade is a direct-fit replacement for factory BMW underseat woofers, delivering significantly deeper and louder bass while working with your original amplifier and audio system.
HOW DO BAVSOUND DELIVER BASS THAT'S LOUDER, CLEANER, AND TIGHTER WITHOUT CHANGING THE FACTORY AMP?
In a word: efficiency.
Every watt of power generated by your factory amplifier produces significantly more bass output with Bavsound's woofers compared to the factory drivers.
If you're not familiar with the concept of efficiency in audio, consider this analogy:
With your factory woofers, your amplifier is like a 200hp engine in a 4,000lb sedan.
With Bavsound woofers installed, it's like putting that same engine into a 2,000lb sports car — dramatically better performance using the same power.
The latest V3 driver design further improves efficiency and bass output compared to earlier subwoofer versions.
YOU WON'T JUST LISTEN TO YOUR MUSIC, YOU'LL FEEL IT
This frequency response graph shows the significantly higher and more balanced output of Bavsound's subs (yellow) compared to factory Harman Kardon subs (white).
Higher and flatter response results in stronger and more controlled bass output.
Up to 2x the bass output — Bavsound's woofers can produce up to 10 dB greater output between 20Hz and 60Hz compared to factory woofers. This results in dramatically stronger bass in the critical sub-bass range.
Nearly flat frequency response provides exceptional linearity across the key bass and mid-bass range from 40Hz to 200Hz (+/- 3 dB), resulting in cleaner and more balanced bass performance.
100% PLUG & PLAY
Installs and fits just like your factory BMW woofers, right down to the mounting points and factory-style connector.
Note: Certain models (such as 2018+ X3 and some vehicles with the Base Stereo system) may require minor modification to the factory enclosure and additional tools.
SIMPLE, DO-IT-YOURSELF INSTALLATION
Installation typically takes 60–90 minutes using basic tools, even for a novice installer. No complex wiring or additional hardware is required. The process simply involves unbolting the front seats, removing the subwoofer covers, unbolting the factory woofers, and installing the Bavsound subwoofers in their place. Once installed, everything connects using the factory plugs and mounting points.
USE YOUR FACTORY AMPLIFIER AND GET EXCEPTIONAL BASS RESPONSE (OR THE REVENANT AMPLIFIER, AND GET EVEN MORE)
Bavsound woofers are designed to maximise the performance of your factory amplifier. They achieve this using technologies such as oversized neodymium magnets and lightweight poly cones to convert every watt of amplifier power into usable bass output. This results in significantly improved bass performance without replacing your amplifier.
Want even more bass? Ask us about the Bavsound Revenant Amplifier upgrade.
SUPER TIGHT, PUNCHY MIDBASS
Your factory underseat woofers don't just reproduce subwoofer frequencies — they also handle important mid-bass frequencies such as kick drums and bass guitar notes.
Bavsound woofers are engineered to outperform the factory drivers across both the sub-bass and mid-bass frequency ranges, resulting in tighter and more impactful bass.
Many aftermarket underseat upgrades only focus on deep bass frequencies and sacrifice mid-bass performance, leaving a noticeable gap in the frequency range.
FACTORY MATCHED IMPEDANCE
Depending on your BMW audio system, factory underseat woofers may use 2 Ohm, 4 Ohm, or 8 Ohm impedance.
Bavsound manufactures different versions of their woofers to match the factory impedance of each system. Matching impedance ensures optimal performance while protecting the longevity of your factory amplifier.
UPGRADEABLE DESIGN WITH 160W RMS / 320W PEAK POWER HANDLING PER WOOFER
Although Bavsound woofers are designed to maximise output using the factory amplifier, they are also built to support amplifier upgrades.
Each woofer can handle up to 160W RMS, allowing them to scale with more powerful aftermarket amplifiers.
If you want extreme bass output, simply add an upgraded amplifier such as the Bavsound Revenant Amplifier.
BAVSOUND'S PRODUCTS ARE BULLETPROOF, SO IS THEIR WARRANTY
All Bavsound products are engineered for durability and long-term reliability.
Every Bavsound speaker upgrade and subwoofer system is backed by a 4-year manufacturer warranty.
If something goes wrong due to a manufacturing defect, we will assist with the warranty process and replacement.
THE PERFECT MATCH TO BAVSOUND'S LEGENDARY SPEAKER AND AMPLIFIER UPGRADES
Improved bass response can dramatically transform your listening experience.
For the ultimate upgrade, the Ghost Underseat Subwoofers pair perfectly with Bavsound's Stage 1 Speaker Upgrade Kit and Revenant Amplifier Upgrade.
Together, these upgrades deliver a complete BMW audio system transformation.
INSTALLATION GUIDES
Note: Professional installation may be recommended on certain later models (such as G05/G06 X5/X6 and G2x 3 & 4 Series) where the factory subwoofers may be bonded into the enclosures. Please contact us if you have any questions regarding installation for your specific model.
FREQUENTLY ASKED QUESTIONS
Can I purchase just the subwoofer enclosure? I already have an amplifier and subwoofer.
Unfortunately not. Bavsound Ghost Subwoofer systems are engineered as complete units, with each component optimised for BMW factory enclosures. As a result, individual components are not available separately.
Will the Ghost Underseat Subwoofers make a big impact in bass response in my BMW?
Yes. The Bavsound Ghost Underseat Subwoofers significantly improve bass output, delivering deeper, tighter, and louder bass compared to the factory woofers.
They also bridge the gap between midrange speakers and deep sub-bass frequencies, resulting in fuller and richer overall sound.
Can I install the Ghost Subwoofer System myself?
If you can assemble IKEA furniture, you can install Bavsound Ghost Underseat Subwoofers.
