CSF Dual-Pass Race-Spec DCT Transmission Cooler - F8x M2 Competition & CS, M3 & M4
The Racing & High Performance Division of CSF Inc. strives to build and engineer the most advanced, efficient, and reliable cooling systems in the world. CSF manufacturers a wide variety of sophisticated cooling systems with more than 117 different applications ranging from high performance all-aluminium direct-fit replacement radiators, to complete custom applications for race cars, power sports, off-road, marine, and industrial uses.
$999.00
Product Information
THE ULTIMATE COOLING SOLUTION FOR BMW F8X M3, M4, & M2 COMPETITION
The BMW F80 M3, F82/F83 M4 & F87 M2 Competiton are still regarded as some of the best performance platforms available. BMW’s S55 Motor has amazing potential for power and there are countless performance parts available for it. However, like most production engines, the S55 doesn’t come equipped from the factory with sufficient cooling capabilities to cope with added power or even prolonged performance driving. CSF have designed a full line of S55 cooling options to help you get the most out of your BMW F8X. The CSF Charge-Air-Cooler, Heat Exchanger, and Transmission Cooler will keep you ahead of the competition.
BMW F8X DUAL-PASS RACE-SPEC DCT TRANSMISSION COOLER
Designed utilising a single row high-pressure 26mm multi-channel microtube, CSF is proud to announce a true plug and play solution to upgrade the DCT Transmission cooler on your F87 M2 Competition & M2 CS, F80 M3 or F82/F83 M4. With a dual-core design, this cooler provides 67% increase in cooling rows for the ultimate in cooling efficiency.
CSF has designed the radiator to fit the stock location and fittings perfectly and is a direct replacement for BMW part number 17112284503.
FEATURES
- Made with CSF's AC condenser technology using a 1-row super-high pressure 26mm multi-channel microtube.
- Dual-pass high performance core with 10 cooling tubes vs OEM single-pass with return pipe 6 tube design.
- High-density multi-louvered fin design.
- Bolt-on fit, requiring no modifications to install. Accepts all attaching OEM components including oil-line connections, mounting brackets, and ducting.
- Lab tested to ~30% more efficient than the stock cooler.
- World's first and only true "plug-and-play" upgraded DCT transmission cooler for the BMW S55 engine in the F8x platform.
Models
- 2 Series / F87 M2 (2016-2021) / M2 Competition
- 2 Series / F87 M2 (2016-2021) / M2 CS
- 3 Series / F80 M3 (2014-2019) / M3
- 3 Series / F80 M3 (2014-2019) / M3 Competition
- 3 Series / F80 M3 (2014-2019) / M3 CS
- 4 Series / F82 / F83 (2014-2019) / M4
- 4 Series / F82 / F83 (2014-2019) / M4 Competition
- 4 Series / F82 / F83 (2014-2019) / M4 CS
- 4 Series / F82 / F83 (2014-2019) / M4 GTS
