Eventuri B58 Carbon Intake System - G4x M240i

Eventuri intake systems use a Patent Pending carbon fibre housing which provides an aerodynamically efficient airflow path from the filter to the MAF tube. Not just another cone filter with a heat shield but a unique design which invokes the Venturi affect.
$2,859.00

Product Information

The BMW G4x B58 Eventuri intake has been developed to provide the turbo with a less restrictive flow path whilst maintaining low inlet temperatures. Heat and volume are the main considerations when designing an intake for turbocharged engines.

In the M240i, the intake system is located next to the exhaust manifold which rapidly heat soaks the engine bay. High temperatures are detrimental for engine performance as the turbo would have to build boost with heated, less dense air and so the only way to ensure IAT’s are kept to a minimum is for a fully sealed intake. This however, results in a restriction with only one stock air feed to draw air in from.

During development Eventuri noticed an additional opening into the wheel arch area and took advantage of this by adding a secondary feed to the airbox. Furthermore the sealed airbox also has a heat shield with gold reflective to minimise the radiative heat transfer from the exhaust manifold.

In order to maximise volume, Eventuri made the airbox as large as possible with a recess for potential strut braces. The stock convoluted intake tube is replaced with a smooth carbon tube which is also larger in internal volume with a starting internal diameter of 111mm (4.4″) smoothly tapering down to match the turbo inlet. The tube provides a smooth path from the filter to the turbo inlet.

Finally a custom made high-flow dry filter is used which is ISO tested for filtration performance and has a larger filtration area than the stock filter.

Performance Gain: 17-20hp, 11-20ft-lb






PERFORMANCE


Dyno Testing

The B58 intake has been independently tested by a US tuner on a B58 Supra (which has the same engine as the G42 M240i) with downpipe and tune. The tests were done back to back on the same day with only the airbox being changed for the Eventuri intake system. As can be seen there is a performance gain for a large portion of the RPM range with some areas showing over 20hp gain. This is the result of derestricting the inlet path while maintaining low inlet temperatures by keeping a fully sealed system.



Another dyno test was carried out in the UK by Evolve Automotive with a downpipe and stage 2 tune. This dyno graph shows the difference between a fully stock Supra and then with the stock airbox, downpipe and stage 2 tune and finally with the Eventuri, downpipe and stage 2 tune. All runs were conducted with the hood closed.




PRODUCT DETAILS


Dual Feed Carbon Fibre Airbox

Crafted from Prepreg Carbon Fibre, the airbox serves 2 objectives - to seal the filter against engine bay heat and to provide a dual cold air feed. Since the airbox is positioned next to the exhaust manifold it is crucial for the filter to be fully sealed so we designed the airbox to encapsulate the filter and at the same time provide a large internal volume. To seal the intake tube Eventuri have designed a laser cut plate with a rubber sealing strip which secures to the airbox. The intake tube passes through the plate and the rubber seal ensures heated air does not enter the airbox. To further minimise heat soak, there is an additional heat shield with a gold reflective layer on the exhaust manifold side which effectively combats the radiant heat transfer.



Having a fully sealed airbox results in the problem of having a restriction for the cold air feed. The stock airbox draws air from a single duct which extends to the front bumper area. During development Eventuri identified another area to draw cold air from which was a gap between the wheel arch and the chassis on which the airbox sits. To utilise this feed they extended a scoop at the back of the design which protrudes into the wheel arch and can even be seen after installation behind the front wheel. This second feed allows the turbo to draw from a larger area therefore reducing the restriction.




Carbon Inlet Tube

The stock inlet tube has a flexible and convoluted section to provide movement with the engine. This however also adds the possibility of turbulence in the flow path as there are multiple faces which can cause eddies. Eventuri replace this with a carbon tube which is smooth and also has a larger internal volume. Unlike most aftermarket intakes we maximised the size of our intake tube, the OEM inlet tube has an internal diameter of 80.8mm or 3.2” at the filter end. The Eventuri tube has an internal diameter of 109mm or 4.3”. This equates to a massive 82% increase in cross sectional area over stock. The tube smoothly tapers down to the stock turbo inlet to ensure airflow remains as laminar as possible. The tube also has CNC machined fitting for the temperature sensor and the breather adapter.







Bespoke Cone Filter

The Eventuri cone filter is made from a non-woven mesh material which is double layered and is ISO tested to ensure that filtration is in line with OEM standards. The filter is cleanable and very stable at high temperatures with the base material being Urethane. The filter incorporates and internal flow guiding cone to help aid the airflow to converge while reducing the possibility of a stagnation point in the middle of the filter space. The filter medium has a significantly larger surface volume than the stock panel filter.




The Art Of Airflow

All the components come together in the engine bay to produce a genuine improvement in the driving experience as well as providing an incredible visual display of form and function in complete harmony.


















KIT CONTENTS


The Eventuri G2x B58 intake system consists of a number of components engineered to perform a specific purpose and fabricated to the highest of standards.

Each intake system consists of:

  • Carbon Fibre Airbox with Dual Feeds
  • Bespoke High Flow Dry Cone Filter
  • Carbon Fibre Inlet Tube
  • CNC Machined Temperature Sensor Mount
  • CNC Machined Breather Adapters
  • Heat Shield with Gold Reflective Backing
  • Laser Cut Stainless Steel Brackets
  • Silicon Reducer with OEM Specification Clamp

Models
  • 2 Series / G42 (2021+) / M240i / M240i xDrive
