Quaife ATB Limited Slip Differential Kit - E9x 323i 325i 330i Auto/Manual

The famous Quaife ATB limited slip differential is one of the world's most popular performance upgrade products for BMW. This unique device transforms the way your car applies power to the road, offering a stunning increase in traction, acceleration, cornering speeds and handling. The Quaife design will work flawlessly with all OE components, will not void your manufacturer's warranty, and comes with its own worldwide lifetime guarantee.
$2,349.00

Product Information

The Quaife ATB (Automatic Torque Biasing) differential is a unique type of limited-slip diff that substantially improves traction for powerful vehicles using only gear mechanisms. This clever design revolutionised the differential market - offering a superior level of performance and warranties compared to its competitors.

We offer two methods of upgrading your E9x 323i, 325i or 330i automatic/manual - we can supply you with the Quaife ATB Limited Slip Differential Kit for you to have the retrofit performed by a specialist yourself or you can send us your differential for an in house conversion to be performed.

Quaife ATB Limited Slip Differential Kit

The Quaife ATB Limited Slip Differential Kit comes with everything you need to retrofit your existing 'open' differential with the Quaife ATB unit. The work is highly recommended to be performed by a differential specialist.

Quaife Limited Slip Differential Retrofit

We offer an in house retrofit service where you can send your differential to us to have the conversion carried out. Depending on your location, the process can take 5-15 days including freight transit time. The cost is also fully inclusive of freight to bring your standard differential to us and the return. All you need to do is organise the removal of your differential (at your own cost) and we can take care of the rest.




MORE ABOUT THE QUAIFE ATB


Why do you need a limited slip differential?

All standard BMW models come from the factory fitted with the basic "open differential" - a simple device that allows the driving wheels to turn at different speeds (enabling the car to navigate around corners). The problem with the open diff is that it can only ever apply the same amount of torque to both driving wheels, so when a wheel slips, it will only put through the amount of torque it requires to power that spinning wheel (very little!). The car spins away power in these instances.

Additionally, BMW use various electronic traction systems that "curb" power to the drive wheels during traction loss (indicated by the flashing traction light on your dashboard). The Dynamic Stability Control system (DSC) is designed to "curb the engine output and stop slip on the wheels", a good feature in theory, but is still in its early stages of development and is way too intrusive, often frustrating the driver when trying to push on. If you accelerate hard from slow speeds, or try to power out of turns (especially in slippery conditions), the loss of traction will make the engine sap power away from the wheels. Turbocharged rear-wheel drive cars with high torque outputs suffer the most, such as BMW's M135i, and conditions are worsened by the fact they are equipped with run-flat tyres and stiff suspensions. Of course if you are lucky enough to have sufficiently deep pockets, all BMW M-Powers come from the factory with a mechanical limited-slip differential, demonstrating that even BMW themselves know that powerful cars need these important devices.

Fortunately, there are clever differentials out there on the aftermarket that will transfer torque to the wheel with more traction rather than take it away...

How does a Quaife ATB differential improve performance?

The Quaife unit uses sets of floating helical cut gear pinions that run in pockets and mesh during normal driving, acting as an open diff. Should one of the driving wheels start to spin however, the helical gears start to generate a torque bias thanks to the axial and radial thrust of the helical gear pinions in their pockets. The result is an instantaneous and progressive transfer of torque away from the spinning wheel to the one with more traction, always varying accordingly and automatically.

With the DSC and traction systems switched off during traction loss, you will feel the Quaife transferring the power to the wheel with more grip in a smooth and predictable manner. Any movement at the rear end is controlled and intuitive for the driver. With the traction systems switched on, you will rarely ever see the light flicker on your dashboard as the Quaife allows you to power through any loss of traction, working in perfect harmony with all of the BMW's standard equipment.

The car ultimately becomes easier to control and is able to apply its power to the tarmac with maximum effect. Acceleration, cornering speeds, handling, steering, and overall dynamics of the car are dramatically improved! The Quaife is capable of varying the torque split from 0-80%, and does this quietly and smoothly in operation. It does not affect any of the traction systems on the car, and does not affect the manufacturer's warranty. All backed by its own worldwide lifetime guarantee.

Watch BBC Top Gear's Chris Harris demonstrate the Quaife ATB in our 335i during his Autocar days.



How is the Quaife ATB superior?

The Quaife ATB Differential provides significantly improved traction and handling for powerful rear-wheel BMWs.

Once installed, drivers will notice an immediate difference as the Quaife automatically biases torque across the axle to the wheel with most grip. Unwanted wheel-slip is greatly reduced, enabling drivers to exploit the full potential of their machines for the first time, leading to a more exciting, rewarding and rapid driving experience.

Widely regarded as the differential upgrade of choice for road car owners, the Quaife ATB was designed to overcome the flaws of conventional clutch-plate limited-slip diffs. Quaife's patented design;

  • requires no servicing or maintenance.
  • is silent and smooth in operation.
  • is guaranteed to work seamlessly with all electronics and OE components.
  • uses a progressive, non-locking helical gear design - allowing for safe and predictable control during moments of oversteer.
  • is capable of biasing up to 80% of torque to wheel with most grip.
  • comes with a limited lifetime warranty.

The clutch-plate problem

'Clutch-plate' limited-slip diffs (BMW M Performance, Drexler, OS Giken, etc) operate using an internal spring pack and set of clutches that limit the amount of rotational difference between the driving wheels in low traction conditions. However, the wearing of clutches means that they require special lubricant changes throughout their lives, and will eventually need replacing. Due to their finite life, many of them can't be guaranteed for more than 12 months.

Additionally if high locking percentages are used they can cause abrupt locking of the rear axle and significant "snap-oversteer" out of slippery turns. While these characteristics might be beneficial in motorsport, they aren't ideal for road use.

The Quaife solution

The Quaife ATB Differential however uses a unique, non-wearing gear design that maximises traction by automatically biasing torque across the axle depending on which wheel is enjoying the most grip. The result in performance is huge amounts of grip, but in comparison to clutch-plate diffs offers an intuitively controllable rear end during any moments of oversteer.

There are no clutches, ramps, springs or other wear prone components to replace at regular intervals, because the Quaife ATB’s well-proven system of helical gears is extremely durable. This makes the Quaife ATB a genuine 'fit and forget' upgrade that offers compromise-free performance and unbeatable reliability on the street, strip, stage or circuit, but most importantly, it can be accompanied with Quaife's famous limited lifetime warranty.

What is the Quaife warranty?

The Quaife ATB Limited-Slip Differential comes with a limited lifetime warranty. If damage is caused to the Quaife due to faulty installation or overheating, the warranty may be voided and repair costs charged.

Our Exchange Quaife Limited Slip Differentials include an additional 24 months warranty on all other final drive components, such as bearings and seals, or if the car is new we will match your manufacturer's warranty.

Will the Quaife ATB affect my new car warranty?

The Quaife ATB will not affect your manufacturer's warranty. Over 3,000 Quaife ATB differentials for BMWs have been sold worldwide, and not one of these has resulted in BMW claiming a fault or defect was as a result of the Quaife installation.

Key features

  • Manufactured in Great Britain
  • Precision manufactured from certified steel billets and inspected to ISO9001-2008 standards
  • Direct replacement for factory standard open differential unit (no 'shims' required)
  • Uses regular gear oil lubrications systems and maintenance schedule
  • Has been consistently tested and improved since its launch in the 1980's
  • Plug and play complete Quaife ATB-equipped differentials available via SouthernBM
  • Comes with technical support by telephone or email via SouthernBM
Models
  • 3 Series / E90 / E91 / E92 / E93 (2005-2013) / 330i
  • 3 Series / E90 / E91 / E92 / E93 (2005-2013) / 325i
  • 3 Series / E90 / E91 / E92 / E93 (2005-2013) / 323i
