Wagner Tuning Top Mount Charge Air Cooler Kit, S55 - F8x M2 Competition & CS, M3 & M4
Since 2002, Wagner Tuning have been developing and producing high quality engine parts, such as intake manifolds, exhaust manifolds, downpipes and intercooler kits. Recent technology advancements coupled with years of experience ensure optimum performance and highest manufacturing precision for customers.
$3,129.00
Product Information
The 3.0 Litre S55B30 turbo engine from BMW F87 M2 Competition & CS*, F80 M3, F82 & F83 M4 models is equipped with an indirect charge-air cooling circuit. So the cooling of the charged air is realised by a water-cooled intercooler which will be replaced by this Wagner Tuning high-performance intercooler. Available with or without a machined WT-logo.
The Wagner Tuning high-performance intercooler has got a new competition core (Tube Fin) with the external core dimensions 287 mm x 185 mm x 115 mm (11.3 Inch x 7.3 Inch x 4.5 Inch). This intercooler core was directly developed for the high requirements of the S55 engine and offers 114 % more external core volume compared to the stock intercooler. The calculated ratio between the inner and outer cooling surface generates a maximum heat transfer and at the same time the best possible internal air flow. The aluminium cast end tanks were designed in CAD and optimized in CFD simulations. The result is an excellent cooling property with a minimal back pressure. That's why this kit is also perfect for racing use. An optimal cooling effect of the charged air with a significant increase in performance!
All Wagner Tuning radiators are equipped with a heat-conductive anti corrosion coating to ensure a lasting cooling effect. The plug & play installation of the system is simple and easy to perform (installation instructions included).
The Wagner Tuning high-performance intercooler has got a new competition core (Tube Fin) with the external core dimensions 287 mm x 185 mm x 115 mm (11.3 Inch x 7.3 Inch x 4.5 Inch). This intercooler core was directly developed for the high requirements of the S55 engine and offers 114 % more external core volume compared to the stock intercooler. The calculated ratio between the inner and outer cooling surface generates a maximum heat transfer and at the same time the best possible internal air flow. The aluminium cast end tanks were designed in CAD and optimized in CFD simulations. The result is an excellent cooling property with a minimal back pressure. That's why this kit is also perfect for racing use. An optimal cooling effect of the charged air with a significant increase in performance!
All Wagner Tuning radiators are equipped with a heat-conductive anti corrosion coating to ensure a lasting cooling effect. The plug & play installation of the system is simple and easy to perform (installation instructions included).
Dimensions OEM intercooler 276 mm x 136 mm x 76 mm, V = 2.85 Litres
Dimensions WT intercooler 287 mm x 185 mm x 115 mm, V = 6.10 Litres
Dimensions WT intercooler 287 mm x 185 mm x 115 mm, V = 6.10 Litres
Features
- Significantly better cooling performance.
- Less pressure drop.
- More power and torque for your engine.
- Mechanical discharge of the turbocharger.
- 100% pressure resistance.
- 100% Plug and Play.
*With slight adjustments inside the hood also fits for BMW M2 Competition & CS.
Packing list
- 1 radiator kit
- 1 mounting material
- 1 installation instruction
Models
- 2 Series / F87 M2 (2016-2021) / M2 Competition
- 2 Series / F87 M2 (2016-2021) / M2 CS
- 3 Series / F80 M3 (2014-2019) / M3
- 3 Series / F80 M3 (2014-2019) / M3 Competition
- 3 Series / F80 M3 (2014-2019) / M3 CS
- 4 Series / F82 / F83 (2014-2019) / M4
- 4 Series / F82 / F83 (2014-2019) / M4 Competition
- 4 Series / F82 / F83 (2014-2019) / M4 CS
- 4 Series / F82 / F83 (2014-2019) / M4 GTS
