Many later F-Series and early G-Series BMW and MINI models built before June-2020 are fitted with Bosch DME/ECU control units that have factory security preventing normal tuning and flashing through the OBDII port.

This is particularly common on vehicles running BMW software from around March 2019 onwards, including models such as the M140i, M240i, M340i, M2 Competition, M3, M4, M5 and M8, along with many other supported BMW and MINI applications.

SouthernBM's DME/ECU Bench Unlock applies the required one-time patch to restore OBDII tuning access, allowing the vehicle to be used with compatible tuning platforms and custom ECU tuning solutions.

The unlock itself does not alter the vehicle's performance or calibration. It simply provides the access required for tuning to take place afterwards.

Once unlocked, the DME/ECU can be accessed through the OBDII port using compatible tuning platforms such as bootmod3, MHD and MG Flasher, as well as supported custom ECU tuning solutions.

The Bench Unlock is not tied to one specific tuning platform, giving you the flexibility to choose the tuning solution that best suits your vehicle and requirements.

Any tuning licence, software or performance calibration is separate from the Bench Unlock unless specifically included as part of another SouthernBM package.

The Bench Unlock removes the factory access restriction that prevents the DME/ECU from being tuned through the vehicle's OBDII diagnostic port.

The control unit is removed from the vehicle and accessed directly on the bench so the required unlock can be applied. Once the DME/ECU is reinstalled, compatible tuning and flashing can then be carried out through the OBDII port.

The Bench Unlock is generally a one-time process and does not add power by itself. The performance changes come from the tune or calibration installed afterwards.

The easiest option for Melbourne-based customers. Simply contact SouthernBM to arrange a booking and bring your vehicle to our Moorabbin workshop. We can handle the process from start to finish, including DME/ECU removal, the Bench Unlock and refitting.

When placing your order online, please select Click & Collect on the shipping page at checkout, as no freight is required for this option.

The advertised product price covers the DME/ECU Bench Unlock only.

Removal and refitting labour is additional and varies depending on the vehicle. The complete process can take around 1–3 hours, depending on the model.

If you're local and comfortable removing the control unit yourself, place your order online first and select Click & Collect on the shipping page at checkout.

Contact us beforehand to arrange a suitable time to bring the removed DME/ECU to our Moorabbin workshop. If you're not confident removing the control unit yourself, we recommend having it removed by an experienced workshop.

Please bring your order confirmation with you so we can match the DME/ECU to your purchase.

If you're outside Melbourne, place your order online first, then remove the DME/ECU and ship it to our Moorabbin workshop for unlocking. If you're unsure about removing the control unit yourself, we recommend having it removed by an experienced workshop.

Please include your order confirmation and contact details with the DME/ECU. We strongly recommend using a tracked shipping service with insurance for the full replacement value of the control unit. Once shipped, please send us the tracking details so we can monitor the delivery.

Return shipping will be calculated and added at checkout based on your delivery address and available shipping options.

Most units received during business hours are unlocked and dispatched back to you the same day, with overnight return shipping used where available. Return timing can vary depending on courier cut-off times and your location.

This service is intended for supported BMW and MINI models built before June-2020 that have a locked DME/ECU preventing OBDII tuning access.

Common applications include vehicles powered by engines such as the B48, B58, S55, N63 and S63, along with other supported BMW petrol and diesel platforms.

Vehicle build date is a useful guide, however the software and ECU fitted to the vehicle ultimately determine whether an unlock is required. Some earlier vehicles may also become locked following BMW dealer programming or software updates.

If you're unsure whether your vehicle requires a Bench Unlock, contact us with your Vehicle Identification Number (VIN) and we can help confirm the correct option before you proceed.

N63 and S63 V8 models use two engine control units. Only one Bench Unlock purchase is required, however both DMEs must be supplied to SouthernBM for the unlock to be completed.

This Bench Unlock for supported vehicles built before June 2020.

BMW, MINI and Toyota GR Supra models produced from 06/2020 onwards may use the newer protected Bosch DME8 or DDE8 control units, which require our newer in-house Bench Unlock solution.

SouthernBM's Pre-06/2020 DME/ECU Bench Unlock includes a 24-month re-unlock guarantee.

If the original DME/ECU becomes locked again due to BMW programming or a software update within this period, we will reapply the unlock at no charge.

Any associated freight, DME removal or refitting labour is not included.

The guarantee applies to the original purchaser and original DME/ECU, subject to our terms and conditions.

No. The Bench Unlock provides the ECU access required for compatible tuning. Any tuning licence, calibration or flashing software is separate unless specifically included in another package.

No. The unlock does not change boost, ignition timing, fuelling or any other performance calibration. Power increases come from the tune installed afterwards.

The unlock is not specific to one tuning platform. Supported vehicles can be used with compatible solutions such as bootmod3, MHD, MG Flasher and custom ECU tuning via the OBDII port, depending on the vehicle and ECU.

Yes, in some cases. Dealer programming or manufacturer software updates can remove existing OBDII tuning access. If this occurs within the 24-month guarantee period, SouthernBM can reapply the Bench Unlock under the conditions outlined above.

Simply send us your Vehicle Identification Number (VIN). We can help determine whether your vehicle requires this Pre-06/2020 Bench Unlock or the newer DME8/DDE8 solution.
