SCC Wheel Spacer Set | LK 120/5 NLB 72.6 | 12mm

SCC is Germany's largest manufacturer of wheel spacer and adaptor systems. With the SCC wheel spacers installed, your car will both look and perform better than it ever has before.
Be the first to write a review
$149.00

Product Information

SCC WHEEL SPACERS | SYSTEM 2

The SCC System 2 hub centric wheel spacers are designed double centering ensure optimum driving behaviour and safety. Extended wheel bolts are additionally required.

Spacer Size 12mm (24mm Per Axle)
Bolt Pattern 5 x 120mm
Centre Bore 72.6mm
Colour Black Anodized or Silver Anodized
Contents 2 Spacers (1 Axle) Per Kit

Features

  • High strength, light weight aluminium/ magnesium alloy.
  • Precision CNC machined.
  • Includes detailed mounting instructions for quick and easy installation.
  • Delivered with TUV or ABE approval.
  • Engineered, manufactured and tested in Germany.
Assembly instructions can be downloaded here.

WHEEL MOUNTING INFORMATION

This spacer set is suitable for use on the following vehicles in combination with the applicable size wheel bolts.


Wheel Bolt M12x1.5mm

Suitable for most BMW models (E-Series) built until 2012.

Length 39mm
Head Size 17mm
Head Shape Cone 60°
Colour Black or Silver
Set Quantity 10 Wheel Bolts

Suitable Models

  • E82, E87 & E88 1 Series including 1 Series M (1M)
  • E36 3 Series including M3
  • E46 3 Series including M3
  • E90, E91, E92 & E93 3 Series including M3
  • E60 & E61 5 Series including M5
  • E63 & E64 6 Series including M6
  • E38 7 Series
  • E31 8 Series
  • E84 X1
  • E36/7/8 Z3 including Z3M
  • E85 & E86 Z4 including Z4M
  • E89 Z4
  • E52 Z8

Wheel Bolt M14x1.25mm

Suitable for most BMW models (F-Series and G-Series) built after 2012.

Length 40mm
Head Size 17mm
Head Shape Cone 60°
Colour Black or Silver
Set Quantity 10 Wheel Bolts

Suitable Models

  • F20 1 Series
  • F22 & F23 2 Series
  • F87 M2, M2 Competiton and M2 CS
  • F30, F31 & F34 3 Series
  • F80 M3 and M3 CS
  • F32, F33 & F36 4 Series
  • F82 & F83 M4, M4 CS and M4 GTS
  • F07, F10 & F11 5 Series including M5
  • F06, F12 & F13 6 Series including M6
  • F01 & F02 7 Series
  • F25 X3
  • F26 X4
  • E70 X5M (This spacer kit is suitable for the rear only)
  • E71 X6 & X6M (This spacer kit is suitable for the rear only)
  • Mini R60 Countryman
  • Mini R61 Paceman

Wheel Bolt M14x1.5mm

Suitable for select BMW models (E-Series) until 2012.

Length 43mm
Head Size 17mm
Head Shape Cone 60°
Colour Black or Silver
Set Quantity 10 Wheel Bolts

Suitable Models

  • E65 & E66 7 Series
  • E83 X3
  • E53 X5

Note: Fitment may not be possible on certain rim or hub types due to the low wheel spacer thickness. Modifications or larger spacers may be required. Please contact us if you have any questions.

Models
  • 1 Series / E82 / E88 (2007-2013) / 1 Series M (1M)
  • 1 Series / E82 / E88 (2007-2013) / 135i N54
  • 1 Series / E82 / E88 (2007-2013) / 135i N55
  • 1 Series / E82 / E88 (2007-2013) / 125i
  • 1 Series / E82 / E88 (2007-2013) / 120i
  • 1 Series / E87 (2004-2011) / 130i
  • 1 Series / E87 (2004-2011) / 120i
  • 1 Series / E87 (2004-2011) / 118i
  • 1 Series / E87 (2004-2011) / 116i
  • 1 Series / E87 (2004-2011) / 123d
  • 1 Series / E87 (2004-2011) / 120d
  • 1 Series / E87 (2004-2011) / 118d
  • 1 Series / F20 (2012-2019) / M140i
  • 1 Series / F20 (2012-2019) / M135i
  • 1 Series / F20 (2012-2019) / 125i
  • 1 Series / F20 (2012-2019) / 120i
  • 1 Series / F20 (2012-2019) / 118i
  • 1 Series / F20 (2012-2019) / 116i
  • 1 Series / F20 (2012-2019) / 118d
  • 2 Series / F22 / F23 (2014-2021) / M240i
  • 2 Series / F22 / F23 (2014-2021) / M235i
  • 2 Series / F22 / F23 (2014-2021) / 230i
  • 2 Series / F22 / F23 (2014-2021) / 228i
  • 2 Series / F22 / F23 (2014-2021) / 220i
  • 2 Series / F22 / F23 (2014-2021) / 220d
  • 2 Series / F87 M2 (2016-2021) / M2 Competition
  • 2 Series / F87 M2 (2016-2021) / M2
  • 2 Series / F87 M2 (2016-2021) / M2 CS
  • 3 Series / E36 (1991-1999) / M3
  • 3 Series / E36 (1991-1999) / 328i
  • 3 Series / E36 (1991-1999) / 325i
  • 3 Series / E36 (1991-1999) / 320i
  • 3 Series / E36 (1991-1999) / 323i
  • 3 Series / E36 (1991-1999) / 318is
  • 3 Series / E36 (1991-1999) / 318i
  • 3 Series / E36 (1991-1999) / 316i
  • 3 Series / E36 (1991-1999) / 323ti
  • 3 Series / E36 (1991-1999) / 318ti
  • 3 Series / E46 (1998-2006) / M3
  • 3 Series / E46 (1998-2006) / M3 CSL
  • 3 Series / E46 (1998-2006) / 330i / 330Ci
  • 3 Series / E46 (1998-2006) / 328i / 328Ci
  • 3 Series / E46 (1998-2006) / 325i / 325Ci
  • 3 Series / E46 (1998-2006) / 323i / 323Ci
  • 3 Series / E46 (1998-2006) / 320i / 320Ci
  • 3 Series / E46 (1998-2006) / 318i
  • 3 Series / E46 (1998-2006) / 325ti
  • 3 Series / E46 (1998-2006) / 318ti
  • 3 Series / E46 (1998-2006) / 316ti
  • 3 Series / E90 / E91 / E92 / E93 (2005-2013) / M3
  • 3 Series / E90 / E91 / E92 / E93 (2005-2013) / 335i N54
  • 3 Series / E90 / E91 / E92 / E93 (2005-2013) / 335i N55
  • 3 Series / E90 / E91 / E92 / E93 (2005-2013) / 330i
  • 3 Series / E90 / E91 / E92 / E93 (2005-2013) / 325i
  • 3 Series / E90 / E91 / E92 / E93 (2005-2013) / 323i
  • 3 Series / E90 / E91 / E92 / E93 (2005-2013) / 320i
  • 3 Series / E90 / E91 / E92 / E93 (2005-2013) / 320d
  • 3 Series / E90 / E91 / E92 / E93 (2005-2013) / 330d
  • 3 Series / F30 / F31 / F34 (2012-2018) / 340i
  • 3 Series / F30 / F31 / F34 (2012-2018) / 335i
  • 3 Series / F30 / F31 / F34 (2012-2018) / 330i
  • 3 Series / F30 / F31 / F34 (2012-2018) / 328i
  • 3 Series / F30 / F31 / F34 (2012-2018) / 320i
  • 3 Series / F30 / F31 / F34 (2012-2018) / 318i
  • 3 Series / F30 / F31 / F34 (2012-2018) / 316i
  • 3 Series / F30 / F31 / F34 (2012-2018) / 318d
  • 3 Series / F30 / F31 / F34 (2012-2018) / 320d
  • 3 Series / F30 / F31 / F34 (2012-2018) / ActiveHybrid 3
  • 3 Series / F80 M3 (2014-2019) / M3
  • 3 Series / F80 M3 (2014-2019) / M3 Competition
  • 3 Series / F80 M3 (2014-2019) / M3 CS
  • 4 Series / F32 / F33 / F36 (2014-2020) / 440i
  • 4 Series / F32 / F33 / F36 (2014-2020) / 435i
  • 4 Series / F32 / F33 / F36 (2014-2020) / 430i
  • 4 Series / F32 / F33 / F36 (2014-2020) / 428i
  • 4 Series / F32 / F33 / F36 (2014-2020) / 420i
  • 4 Series / F32 / F33 / F36 (2014-2020) / 420d
  • 4 Series / F82 / F83 (2014-2019) / M4
  • 4 Series / F82 / F83 (2014-2019) / M4 Competition
  • 4 Series / F82 / F83 (2014-2019) / M4 CS
  • 4 Series / F82 / F83 (2014-2019) / M4 GTS
  • 5 Series / E60 / E61 (2003-2010) / M5
  • 5 Series / E60 / E61 (2003-2010) / 550i
  • 5 Series / E60 / E61 (2003-2010) / 545i
  • 5 Series / E60 / E61 (2003-2010) / 540i
  • 5 Series / E60 / E61 (2003-2010) / 530i
  • 5 Series / E60 / E61 (2003-2010) / 525i
  • 5 Series / E60 / E61 (2003-2010) / 523i
  • 5 Series / E60 / E61 (2003-2010) / 530d
  • 5 Series / E60 / E61 (2003-2010) / 520d
  • 5 Series / F07 / F10 / F11 (2010-2017) / M5
  • 5 Series / F07 / F10 / F11 (2010-2017) / 550i
  • 5 Series / F07 / F10 / F11 (2010-2017) / 535i
  • 5 Series / F07 / F10 / F11 (2010-2017) / 528i
  • 5 Series / F07 / F10 / F11 (2010-2017) / 520i
  • 5 Series / F07 / F10 / F11 (2010-2017) / 535d
  • 5 Series / F07 / F10 / F11 (2010-2017) / 530d
  • 5 Series / F07 / F10 / F11 (2010-2017) / 520d
  • 6 Series / E63 / E64 (2003-2010) / M6
  • 6 Series / E63 / E64 (2003-2010) / 650i
  • 6 Series / E63 / E64 (2003-2010) / 645Ci
  • 6 Series / F06 / F12 / F13 (2011-2018) / M6
  • 6 Series / F06 / F12 / F13 (2011-2018) / 650i
  • 6 Series / F06 / F12 / F13 (2011-2018) / 640i
  • 6 Series / F06 / F12 / F13 (2011-2018) / 640d
  • 7 Series / E38 (1994-2001) / L7
  • 7 Series / E38 (1994-2001) / 750i / 750iL
  • 7 Series / E38 (1994-2001) / 740i / 740iL
  • 7 Series / E38 (1994-2001) / 735i / 735iL
  • 7 Series / E38 (1994-2001) / 730i / 730iL
  • 7 Series / E65 / E66 (2001-2008) / 760Li
  • 7 Series / E65 / E66 (2001-2008) / 750i / 750Li
  • 7 Series / E65 / E66 (2001-2008) / 745i / 745Li
  • 7 Series / E65 / E66 (2001-2008) / 740i / 740Li
  • 7 Series / E65 / E66 (2001-2008) / 735i / 735Li
  • 7 Series / F01 / F02 (2008-2016) / 760Li
  • 7 Series / F01 / F02 (2008-2016) / 750i / 750Li
  • 7 Series / F01 / F02 (2008-2016) / 740i / 740Li
  • 7 Series / F01 / F02 (2008-2016) / 730d
  • 8 Series / E31 (1990-1999) / 850CSi
  • 8 Series / E31 (1990-1999) / 850Ci
  • 8 Series / E31 (1990-1999) / 850i
  • 8 Series / E31 (1990-1999) / 840Ci
  • X1 Series / E84 (2009-2015) / X1 28i
  • X1 Series / E84 (2009-2015) / X1 25i
  • X1 Series / E84 (2009-2015) / X1 20i
  • X1 Series / E84 (2009-2015) / X1 18i
  • X1 Series / E84 (2009-2015) / X1 23d
  • X1 Series / E84 (2009-2015) / X1 20d
  • X1 Series / E84 (2009-2015) / X1 18d
  • X3 Series / E83 (2003-2010) / X3 30Si
  • X3 Series / E83 (2003-2010) / X3 30i
  • X3 Series / E83 (2003-2010) / X3 25Si
  • X3 Series / E83 (2003-2010) / X3 25i
  • X3 Series / E83 (2003-2010) / X3 30d
  • X3 Series / E83 (2003-2010) / X3 20d
  • X3 Series / F25 (2011-2017) / X3 28i
  • X3 Series / F25 (2011-2017) / X3 20i
  • X3 Series / F25 (2011-2017) / X3 30d
  • X3 Series / F25 (2011-2017) / X3 20d
  • X4 Series / F26 (2014-2018) / X4 35i
  • X4 Series / F26 (2014-2018) / X4 20i
  • X4 Series / F26 (2014-2018) / X4 35d
  • X4 Series / F26 (2014-2018) / X4 30d
  • X4 Series / F26 (2014-2018) / X4 20d
  • X5 Series / E53 (1999-2006) / X5 4.8is
  • X5 Series / E53 (1999-2006) / X5 4.6is
  • X5 Series / E53 (1999-2006) / X5 4.4i
  • X5 Series / E53 (1999-2006) / X5 3.0i
  • X5 Series / E53 (1999-2006) / X5 3.0d
  • X5 Series / E70 (2007-2013) / X5M
  • X6 Series / E71 (2008-2014) / X6M
  • X6 Series / E71 (2008-2014) / X6 50i
  • X6 Series / E71 (2008-2014) / X6 35i
  • X6 Series / E71 (2008-2014) / X6 M50d
  • X6 Series / E71 (2008-2014) / X6 40d
  • X6 Series / E71 (2008-2014) / X6 35d
  • X6 Series / E71 (2008-2014) / X6 30d
  • Z Series / E36/7/8 Z3 (1995-2002) / Z3M
  • Z Series / E36/7/8 Z3 (1995-2002) / Z3 3.0i
  • Z Series / E36/7/8 Z3 (1995-2002) / Z3 2.8i
  • Z Series / E36/7/8 Z3 (1995-2002) / Z3 2.2i
  • Z Series / E36/7/8 Z3 (1995-2002) / Z3 2.0i
  • Z Series / E36/7/8 Z3 (1995-2002) / Z3 1.9i
  • Z Series / E52 Z8 (1999-2002) / Z8
  • Z Series / E52 Z8 (1999-2002) / ALPINA Z8
  • Z Series / E85 / E86 Z4 (2002-2008) / Z4M
  • Z Series / E85 / E86 Z4 (2002-2008) / Z4 3.0Si
  • Z Series / E85 / E86 Z4 (2002-2008) / Z4 3.0i
  • Z Series / E85 / E86 Z4 (2002-2008) / Z4 2.5Si
  • Z Series / E85 / E86 Z4 (2002-2008) / Z4 2.5i
  • Z Series / E89 Z4 (2009-2016) / Z4 35is
  • Z Series / E89 Z4 (2009-2016) / Z4 35i
  • Z Series / E89 Z4 (2009-2016) / Z4 30i
  • Z Series / E89 Z4 (2009-2016) / Z4 28i
  • Z Series / E89 Z4 (2009-2016) / Z4 23i
  • Z Series / E89 Z4 (2009-2016) / Z4 20i
  • MINI / R60 Countryman (2010-2016) / Cooper D
  • MINI / R60 Countryman (2010-2016) / Cooper SD
  • MINI / R60 Countryman (2010-2016) / Cooper
  • MINI / R60 Countryman (2010-2016) / Cooper S
  • MINI / R60 Countryman (2010-2016) / JCW
  • MINI / R61 Paceman (2012-2016) / Cooper
  • MINI / R61 Paceman (2012-2016) / Cooper S
  • MINI / R61 Paceman (2012-2016) / JCW

Be the first to write a review

Thanks for submitting your review!
Please note, all reviews must be approved before they are published.
Your Rating
First Name
Last Name
Email Address
Keep me updated with news and exclusive offers
Location
Review Title
Review Comment
Submit Review

You might also like…

CSF High-Performance Automatic Transmission Oil Cooler w/ Rock Guard (S58) - G8x M2, M3, M4
$1,189.00
Quaife ATB Limited Slip Differential Retrofit - F2x M135i M235i
$4,899.00
APEX Stud Kit | M12x1.5mm | 5-Lug
$350.00
Sterckenn F87 M2 Competition Carbon Front Splitter
$1,399.00
Bavsound Stage 1 Speaker Package - G42/G87 2 Series & M2 with S688A Harman Kardon
$1,249.00
APEX SM-10RS Forged Sprint | 18" x 10.5" ET22 | 5x120mm | 72.56mm
$1,520.00
Free shipping on orders over $1,000*
Local warranty & support
30 day money back guarantee
100% Secure checkout

Great experience dealing with the team at SouthernBM. Sean in particular was fantastic with his knowledge, timely responses and ultimately work performed.

Ian Tennent
Google Review

Seriously great service and people. Honest and fair. Would happily recommend anyone to them.

Amir Pali
Facebook Review

Excellent service at reasonable prices. The shop is very nice too, you almost feel like you're at BMW.

Charles Tey
Facebook Review

Andrew Brien @ Southern BM has been helping me for years with my BMWs - he is extremely astute and has a refreshingly customer-first mentality. I trust him to do the best work and only the best!

Leo Ng
Google Review

Extremely happy and love this place. Great service from Eric. Bought and installed akrapovic exhaust system from this place. Also purchased and installed the M performance bonnet. 100% coming back for more service from this place.

Timothy Sung
Google Review
Watch the video

Company

Explore

Support

Stay up to date

You've just been sent an email to confirm your email address. Please click on the link in this email to complete your subscription.
Subscribe

We respect your privacy − read our policy.

PayPal Logo
© 2024 SouthernBM. All Rights Reserved.

Please sign in

Email Address
Password
Log In Forgot your password?
Don't have an account? Register

Stay up to date

You've just been sent an email to confirm your email address. Please click on the link in this email to complete your subscription.
First Name
Last Name
Email Address
Subscribe

We respect your privacy − read our policy.

Need help?

Make a booking We can handle everything from servicing to major diagnosis and repairs.
Location Find our address and location on a map.
Phone Available during office hours.
Email If you have any questions we'd love to hear from you.

Stock Availability

In Stock Items marked GREEN or 'In Stock' are currently in stock at SouthernBM. Most orders are shipped within 1-2 business days. ‘Click & Collect’ orders are usually ready within 1-2 hours during normal trading hours.
Available to Order Items marked YELLOW or ‘Available To Order’ are not currently in stock at SouthernBM, and need to be ordered in from the supplier. Please note the expected delivery time before placing an order.
No Longer Available Items marked RED or ‘No Longer Available’ have been discontinued and are no longer available to be ordered. Please contact us for an alternative.
All orders are dispatched from our Melbourne warehouse. Most orders are delivered within 1-3 business days Australia-wide after dispatch. The expected delivery time on all 'Available To Order' items is only an estimate and wait times may vary from those provided. Please contact us if you have any questions.

All items listed on our website are not available for in store pick up without prior purchase. Please use the ‘Click & Collect’ option at checkout and we will let you know as soon as your order is ready.

Make a booking

Thanks! We've received your request. We will be in touch within 1 business day to confirm your booking. If you do not see the email in this time, please check your JUNK/SPAM folder.
Preferred Date
Drop Off Time
Vehicle
Registration #
First Name
Last Name
Email Address
Keep me updated with news and exclusive offers
Phone
How can we help?
Send Request
By clicking the Send button, you acknowledge that this form is a request for service and not a confirmation.
